FLIR DM286 USER MANUAL Document Identifier: DM286-en-US_AA
8.5 Image and Video Capture
Short press to save a thermal image. Long press to start recording video; short
press to stop recording. Up to 30k images can be stored in the meter’s 4 GB internal
memory. Videos up to 50 minutes in length can be recorded.
Saved thermal images are fully radiometric (each pixel includes temperature
measurement data). To view radiometric data within captured thermal images, send
the images to a mobile device using the METERLiNK app.
Note that the imager must be fully initialized before radiometric data can be captured.
Allow several minutes after powering the meter before taking readings.
From the meter you can view, share, and delete images and video as explained below.
8.6 Image and Video Gallery
Follow the steps below to view and process images and video.
1. Press OK to open the Main Menu.
2. Press OK at the Gallery
icon.
3. Press OK on the Images/Video menu.
4. Use the left/right arrow buttons to scroll to an image or video.
5. Press OK to open a selected image or video. Press OK again to open a menu that
offers the following actions:
View full screen (images only) or start video playback
Share media with mobile devices (Section 11)
View image name, date, and time
Permanently remove image or video
6. Press the Return button
to exit.
8.7 Share Images and Video with METERLiNK
Share images with a mobile device running the METERLiNK app. Refer to Section 11
for more information.
1. With an image opened, press OK.
2. Scroll to the Share icon
and press OK to begin transmitting the image.
Note that videos > 30 seconds in length cannot be transmitted. Videos
approximately 30 seconds in length will require 3 to 4 minutes transmission time.
