9.13 Continuity Test
Warning: Do not perform diode, resistance, or continuity tests before removing the
power from capacitors and other devices under test during a measurement. Injury to
persons can occur.
1. Refer to Fig. 9.5. Set the function switch to the position.
2. Use the
button to select continuity. The indicator will be displayed.
3. Insert the black probe lead into the negative COM terminal and the red probe
lead into the positive terminal.
4. Touch the tips of the probe across the circuit or component under test.
5. If the resistance is < 10 Ω the meter beeps. If the resistance is > 100 Ω the meter
will not beep. > 10 Ω but < 100Ω the beeping will stop at an unspecified point.
