FLIR DM286 USER MANUAL Document Identifier: DM286-en-US_AA
32
9.4 Data Hold in MultiMeter Mode
In Data Hold mode, for all measurement modes except thermocouple mode, the
primary display digits are held. In thermocouple mode, the temperature reading in
both
o
F and
o
C are held. To enter/exit Data Hold mode, short press the (hold)
button. In Hold mode, the
indicator is displayed.
9.5 Menu Icons
Menu icons displayed in the IGM mode are explained in Section 8.
There are 5 main options in the Menu bar. See Section 6, Menu System.
Image Mode Menu (Section 8.4). Available only when the thermal
imager is open.
Thermal Settings Menu (Section 8.3, Thermal Settings Menu).
Available only when the thermal imager is open.
Image, Video, and Data Log Gallery (Sections 8
.5 and 8.6)
Advanced Menu (Section 6.2)
Settings Menu (Section 7)
Fig. 9.2 Menu icons
• Use the Left / Right buttons to move the cursor.
• Press the OK button to select an option.
• If an option is disabled (grayed) it is not available in the currently active mode.
9.6 VFD (Low Pass Filter)
VFD eliminates high-frequency noise from AC current and voltage measurements using
a low-pass filter.
Long press the MODE button to add/remove the low pass filter to the measurement,
the VFD icon
will appear in this mode.
