14.4.6 - Continuity
Function Symbol Resolution Action
Input
Protection
(sine wave)
Continuity (Ω) 0.1 Ω
≤ 10 Ω = beeper ON
1000 V RMS
≥ 100 Ω = beeper OFF
Additional Continuity Notes
1. Measurements between 10 and 100
Ω may or may not cause the beeper to sound
2. Current < 1.5 mA
14.4.7 - Diode
Function Symbol Resolution Action
Input
Protection
(sine wave)
Diode 0.001 V
Silicon PN junction with
forward voltage bias = 0.5
to 0.8 V
1000 V RMS
Additional Diode Note
1. Open circuit voltage = 3V approximately.
14.4.8 - Capacitance
Function Range Resolution Accuracy
Input
Protection
(sine wave)
Capacitance (F)
600.0 nF 0.1 nF
± (2.0% + 5d)
1000 V RMS
6.000
μ
F
0.001
μ
F
60.00 μF 0.01 μF
600.0 μF 0.1 μF
± (4.0% + 5d)
10.00 mF 0.01 mF
Additional Capacitance Notes
1. Residual readings: ≤ 10 digits (input jacks open circuit)
2. Measured value = display value minus short circuit value
3. Assurance accuracy range: 5 to 100% of range
