Using the Main Menu15
NOTE
In order to enable Snapshot recording, the following menu options must be configured:
• The Snapshot schedule must be enabled for times that you would like to save snapshots. See 15.3.15
Configuring the Snapshot Schedule, page 77.
• Snapshot recording must be enabled for motion detection in the Event menu. See 15.3.7 Configuring
Motion Detection, page 66.
To configure snapshot recording settings:
1. From the Main Menu, click
and select Recording>Snapshot.
2. Under Snap Number, select the number of snapshots the system will take when the
snapshot button is pressed.
3. Configure the following settings for snapshots saved automatically from motion detec-
tion or the snapshot schedule:
• Channel: Select the channel you would like to configure.
• Mode: Select Timing for the system to take snapshots according to the snapshot
schedule (see 15.3.15 Configuring the Snapshot Schedule, page 77) Select Trig-
ger for the system to take snapshots only when triggered by motion detection
(snapshot must be enabled in the Motion Detect menu (see 15.3.7 Configuring Mo-
tion Detection, page 66).
• Image Size: Select the resolution for snapshots.
• Image Quality: Select the snapshot image quality between 1 (lowest) and 6
(highest).
• Snapshot Frequency: Select the number of snapshots (up to 6) the system will
take each time.
4. Click OK to save changes.
#LX400096; r.45547/45547; en-US
48
