FLIR X-Series User Manual

4 – Installation
X-series User’s Manual 16
Item
Category
Description
detect and configure itself to work with this kind of cable. The GigE
interface is not capable of handling the full data rate of the camera.
It can handle about 125Hz at full resolution.
3
Video/USB
HDMI video output, USB-2 port and microSD card slot (not yet
implemented)
4
Digital Data
Camera Link Full
The X6800sc has an industry standard Camera Link Full interface
using MDR connectors. This interface can handle the full data rate
of the camera.
5
Sync
Sync input and output connectors
6
Auxiliary
This is the Auxiliary connector which is described in Section 6.2.10.
7
Record
This record input will trigger the recording to the internal RAM buffer I
the camera. The input can be a contact closure or a rising-edge TTL
pulse.
