Power button. DC power connector.
Plug in the AC power supply to a standard outlet. The power supply
is compatible with 120V/60Hz and 240V50Hz AC power. Plug
adapters can be used for different regions. Connect the DC power
cable between the power supply and the power connector located on
the rear panel of the X6800sc camera. Turn on the camera by
pressing the power button on the rear panel. The button will
illuminate to indicate that the unit is ON.
Gigabit Ethernet
The X6800sc has a Gigabit Ethernet interface that is GigE Vision
compliant. Use a regular CAT5e or CAT6 Ethernet patch cable. If a
crossover cable is used, the camera interface will automatically
