FLORA pp2512uv - Raster Reader and Strip; Detecting Sensor; Limited Switch

Victor Xu Page 31 12 Jan. 2011
Copyright 2011 © Shenzhen Runtianzhi Image Technology, Co., Ltd.
http://www.floradigital.com
4.4.3.2 Raster reader and strip
The Raster Encoder and Raster Strip are installed inside the back plate of carriage
besides the worm gear for moving the carriage up and down.
4.4.3.3 Detecting sensor
Detecting sensor is supplied to detect the distance from the print head to media.
4.4.3.4 Limited switch
These limit switches are installed at the right side upper portion of the carriage. The
Encoder
200DPI Raster
e
n
code
r
200DPI
R
aste
r
St
ri
p
Removed Cover
Front of Carria
g
e
Detecting Sensor
Electromagnet
Enlarge View
Plastic Disc
Cable connections Illustration for Carriage Height Adjustment Module
A
+
A-
B+
B-
BC
A
C +
5Vdc
Pulse
DIR
+24Vdc
GND
Photographic Side View of Height Adjustment Module
