Chapter 5 – Installation manual of Flora PP 2512UV
5.1 Pre-Installation Requirement
¾ The minimum working area should be 610 cm x 585 cm, this includes the space for the
operator to move around the machine conveniently and safely.
¾ Prepare the necessary AC plug on the power cord attached to the machine. Please see the
Technical Specification table for the power requirements.
¾ If the PC is not supplied with the machine, customer must meet the minimum PC
specification requirement to be used in this machine
9 Intel Core 2 Duo, Pentium IV 2 GHz，2G RAM, 250G Hard disk
9 DVD Drive,
9 USB Port for Hardware Key and USB cable
9 Windows XP Professional Service Pack 2
9
LCD monitor
¾ Safety signs must be available within the working area.
¾ Exhaust System must be provided for the solvent and Ink fumes. Please note that fumes
are heavier than air so it is most likely the concentration happens at the lower level of the
room.
¾ Lightings should be sufficient enough.
¾ Flammable Storage Cabinet for the Ink and flushing solution stock is highly recommended
to secure them very well.
¾ Waste Container should be available for ink and flushing liquid waste as well as ink/solvent
contaminated cloth inside the Printing area.
¾ Waste disposal should be in accordance with your local laws governing Hazardous Waste
Disposal.
5.2 Machine Pre-Installation
Once the machine is placed and all spare parts are thoroughly checked, start doing the following
pre-installation activities;
Install the automatic Feeding and Take-up Rollers if applicable.
Removed the Tie Wires which hold the Print head Carriage from moving.
Check the height of the Print head Carriage over the printing platform. The height should be at
least 2mm above the media printing surface.
Check the movement of the Print head Carriage for any obstruction by moving it manually from
one end to the opposite end.
Prepare the necessary power source for the machine.
Install the LCD Panel / Monitor and the PC, keyboard and mouse to be used on this machine.
Place the CPU to the computer compartment provided if applicable.
5.3 Installation of software
5.3.1 Installation Procedure of PhotoPRINT Server Flora Edition 6.1v2
1) Turn-on the Main Power to give power to the PC and Monitor.
2) Insert the CD supplied with the machine with label Photo Print 6.1V2 for the necessary
installation.
3) The screen will prompt you with 【Choose Setup Language】 window; Select which
language you will use. Then click “OK”. Then with Starting 【InstallShield Wizard…. 】
