Left UV Lamp:
-Left bulb: when it lighted up, that means the left UV bulb will turn on when it moving
to left.
-Right bulb: when it lighted up, that means the left UV bulb will turn on when it moving
to right.
Right UV Lamp:
-Left bulb: when it lighted up, that means the right UV bulb will turn on when it moving
to left.
-Right bulb: when it lighted up, that means the right UV bulb will turn on when it
moving to right.
Add pass:
-Add Number: before finish job printing, it will print more passes to dry the ink.
6.4.6.6 Temperature Tab
Refer to 5.5.2 for more detail.
6.4.6.7 Voltage Tab
Refer to 5.5.2 for more detail.
6.5 Shut-off procedure
6.5.1 Over-night protection
Shut off the UV lamps
Shut off the negative pressure valves.
Shut-off the power for machine and PC
Close the machine covers
Do housekeeping if necessary
6.5.2 Long term protection
Shut-off the UV lamps.
Shut-off the negative pressure valves.
Shut-off the power for machine and PC.
Disconnect the print head input tube from the Ink Supply line.
Connect the print head input line to the syringe filled with clean applicable flushing
solutions.
Slowly push the flushing solution out of the Print head to gradually remove the ink
presence on the Print head.
Continue flushing the print head until a clear flushing solution are jetting out of the print
head nozzles.
Re-connect the print head input tube to ink supply line.
Do the same procedure on other Print heads.
After completing the flushing of all the Print head, prepare the Print head Capping
material.
Pour Flush solution to the lint free cloth on top of the prepared print head capping
material.
Install the Print head Capping into the bottom of the Print head Carriage securing it
with the cling wrap which is wrapped-around the print head carriage
Wipe-off any ink contamination.
Turn off the Main Power switch.
