7.4.3 Maintenance of Z-axis
Media Height Auto Adjustment System should be clean and lubricate applicable parts weekly.
7.4.4 Maintenance of auto-clean system
Print head Wiping System should be clean and lubricate applicable part weekly.
Media Height Adjustment System
Worm Gear
Assembly
200DPI
Raster
Reader
200DPI
Raster Strip
Media Height Sensor Assembly
Media Height
Sensor
Media Height
Sensor
Printhead Wiping System
Timing
Belt
Belt Gear
Pulley
Timing Belt
Tension adjuster
Servomotor
