Fluke 43B Service Manual

Performance Verification
4.5 Input 1 and Input 2 Tests in the SCOPE MODE.
4
4-21
• Press to highlight DC Coupling.
• Press
to confirm;  mark changes to ■.
• Press
select Input 2 READING.
• Press
to select the Input 2 READING.
• Press
to highlight Peak m/m.
• Press
to confirm;  mark changes to ■.
• Press
to highlight Input 2 Coupling.
• Press
to select the Input 2 COUPLING.
• Press
to highlight DC Coupling.
• Press
to confirm;  mark changes to ■.
• Press
to return to SCOPE.
4. Set the 5500A to source a sine wave, to the first test point in Table 4-5 (NORMAL
output, WAVE sine).
5. Observe the Input 1 and Input 2 main reading and check to see if it is within the
range shown under the appropriate column.
6. Continue through the test points of table 4-5.
7. When you are finished, set the 5500A to Standby.
Table 4-5. Volts Peak Measurement Verification Points
5500A output, Vrms (sine) 5500A Frequency Reading 1 Reading 2
1.768 (5V peak) 1 kHz 4.50 to 5.50 4.50 to 5.50
4.5.12 Input 1 and 2 Phase Measurements Test
Proceed as follows:
1. Connect the test tool to the 5500A as for the previous test (see Figure 4-5).
2. Select the AUTO test tool setup:
• Press
to select the MENU.
• Press
till SCOPE is highlighted.
• Press
to select SCOPE mode
3. Select DC coupling for Input 1 and 2; Reading Phase for Input 2:
• Press
to select menu SCOPE SETUP.
• Press
to highlight Input 1 Coupling.
• Press
to select the Input 1 Coupling menu.
• Press
to highlight DC Coupling.
• Press
to confirm;  mark changes to ■.

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
