Performance Verification
4
4-31
4.10 VOLT/AMPS/HERTZ.
Proceed as follows to test VOLT/AMPS/HERTZ:
1. Connect the test tool to the 5500A as for the previous test shown in Figure 4-9.
2. Press
3. Press to highlight VOLT/AMPS/HERTZ.
4. Press
to select VOLT/AMPS/HERTZ.
5. Set the 5500A to source the AC voltages in the table (NORMAL output, Wave sine)
and check the readings.
6. When you are finished, set the 5500A to Standby.
Table 4-10. Volts/AMPS/HERTZ verification points
5500A output 5500A Freq. Reading1 Reading 2
Volt Hertz Kilo-Amperes
0 ± 10 counts ± 10 counts
5.5V 70Hz 5.34 - 5.66 69.4 - 70.6 5.34 - 5.66
4.5V 70Hz 69.4 - 70.6 4.445 - 4.555
4.11 POWER.
Proceed as follows to test POWER:
1. Connect the test tool to the 5500A as for the previous test shown in Figure 4-9.
2. Press
3. Press to highlight POWER.
4. Press
to select POWER.
5. Set the 5500A to source the AC voltages in the table (NORMAL output, Wave sine)
and check the readings.
6. When you are finished set the 5500A to Standby.
Table 4-11. Power Measurement Verification points
5500A output Reading
Input 1 Input 2 kW kVA kVAR PF DPF Hz
00± 4 counts ± 4 counts ± 4 counts
4.472V/60Hz 4.472/60Hz 19.4-20.6 19.4-20.6 ± 4 counts 0.96-1.00 0.97-1.00 59.5-60.5
5.916V/60Hz 5.916V/60Hz 34.3-35.7 34.3-35.7 ± 4 counts 0.96-1.00 0.97-1.00 59.5-60.5
