111
Editing ange conguration
A typical vertical machine train arrangement consists of machines mounted
together using a bolted ange. To congure the ange proceed as follows:
1. Once in the “Edit ange” screen use the navigation keys to cycle through the
ange pattern parameters that may be edited. These include:
● Shape and dimensions of ange
● Bolt pattern and number of ange bolts
2. Use the navigation keys to cycle through the elements in the “Edit ange”
screen.
3. With the ange highlighted, press
ENTER
.
The following ange patterns are available:
● Circular ange – circular bolt pattern
● Square/Rectangle ange – square/rectangular bolt pattern
● Square/Rectangle ange – circular bolt pattern
● Circular ange – square/rectangular bolt pattern
Vertical flanged machines
Editing flange configuration
