Network Assistant
Specifications
125
Cable Types
• Unshielded Twisted Pair LAN cables (100 UTP category 3, 4, 5, 5E, and 6 ISO/IEC Class C and D)
• Foil-screened Twisted Pair cables (100 and 120 Ohm ScTP category 3, 4, 5, and 6 ISO/IEC Class C and D)
• Identifies and operates with the optional fiber adapter, LX (1310nm, -3 dBm (0.50 mW max)),
SX (850nm, -2 dBm (0.63 mW max)), and ZX (1550nm, +4 dBm (2.5 mW max)).
Cable Length
Note
Length accuracy depends on the cable type selected on the Cable Verification screen.
Open, shorted or with wiremap adapter 1 to 305 m (3 ft. to 1000 ft.)
Terminated with ≥ 20 % reflection 1 to 305 m (3 ft. to 1000 ft.)
Receive Level
100 to 5000mVp-p
