Measure task
What is a measure task?
To measure a location, the device requires information on type of parameter to be measured,
type of sensor used, and if necessary, data for the evaluation of the result. If the RPM must be
recorded, this information is also required. This data set is a measure task.
The device contains a full collection of measure tasks generated based on task templates. It is
possible to create user defined measure tasks.
Measure tasks can be assigned to any measure location as shown in the previous image and
described as follows:
The selected measure location with the name M DE a meas-
ures the parameter vibration.
Tap to see measure tasks assigned to the selected loc-
ation M DE a.
The measure tasks assigned to the selected location M DE a.
Tap to assign a new measure task to the selected location
M DE a .
62 Version:1.0
