Trending spectrum
Vibration results shown in VIBXPERT 3 are based on the trending spectrum.
What is a trending spectrum?
A trending spectrum is a mode that measures vibration and delivers the measured signal as a
spectrum (standard spectrum, envelope spectrum or and order-based spectrum), time wave-
form, and trending parameters. Trending parameters include: RMS, Zero-Peak, Peak-Peak,
Overall values
Understanding results
After a location has been measured, results are shown immediately.
Note:Results remain on display depending on the time option selected under Results
Display in Settings..
Shown results depend on the applied measure tasks. The measure tasks can be seen in the
measurement screen.
Tap the parameter icon ( ) (in this case vibration) to see the applied measure tasks (
) for the selected location.
94 Version:1.0
On-board help
