Ford F-MAX - Power Take Off

4
OPERATION
- 127 -
Power Take O
Illustration is for informational purposes
only. There are no adaptors or pumps on
the vehicle.
PTO is the unit connected to the
transmission to operate the equipment
that will be operated by taking power
from the transmission (such as pumps).
It transmits the power it takes from the
transmission to the pump.
PTO installation is optional and can
be performed on both manual and
automated transmissions during
production in the factory.
Contact a Ford Trucks authorized
dealership for the retrospective PTO
installations.
Engine electronic control unit allows that
the engine is operated at a constant speed
when PTO is activated. Maximum speed
and function start parameters on the
control unit may be set by a Ford Trucks
authorized dealer.
The following preconditions shall be met
for engine speed control:
service. The vehicle shall be stationary,
service. Transmission shall be shi ed to N,
service. The handbrake must be applied.
To activate the function:
service. Press the “RES” button on the
steering wheel, engine speed shall switch
to function start speed service. When
you use tyhe “SET+” and “SET-” buttons,
engine speed shall be increased and
decreased with increments that may also
be changed by the authorized service.
• PTO may only be activated when the
vehicle is stationary and rotating knob is
at position "N".
• PTO is activated by pressing the PTO
button on the console.
• Shi ing is not possible when PTO is
activated and vehicle is moving.
• PTO cannot be activated when the
vehicle is moving.
•
symbol shall be illuminated on
the functions section of instrument
when PTO is active.
Power take o
