4
OPERATION
- 64 -
Opening/closing the front hood
2
1
To open:
Bring the opening lever under the hood
from position (1) to position (2) as shown
with an arrow. Raise the hood slightly,
pistons shall open the cover.
To close:
• Pull the hood from open position by the
strap.
• To latch the hood, push from the marked
side points.
CAUTION
Make sure the hood is fully latched.
WARNING
Pull/push the hood from center only for
opening and closing operations.
Do not push the hood at center area for
locking operations.
Toolbox
Toolbox is located behind the driver and
passenger doors as shown in the fi gure.
You may open it by pulling the ring on the
side of the driver and passenger seats
while the door is open.
Note: When the toolbox is opened for
90 degrees, it shall be kept open at 90
degrees thanks to the tensioner, it may
be closed when it is pulled with a certain
force.
Opening and closing of the vehicle
