Ford F-MAX - Side Shroud

MAINTENANCE AND SERVICE
5
- 177 -
Side shroud
1
Side shroud is opened by holding it from
the top and bottom as shown in the fi gure
and then pulling it to the outside (2) of
the vehicle and then to the front (2) of the
vehicle.
2
Closing is complete by pulling it
backwards only.
Driver Cab
