MAINTENANCE AND SERVICE
5
- 206 -
PARTS PART NAME LOCATION
JACK
ON THE TOOLBOX
BEHIND THE
PASSENGER SEAT
TOOLBOX
ON THE TOOLBOX
BEHIND THE
PASSENGER SEAT
WHEEL NUT
WRENCH
ON THE TOOLBOX
BEHIND THE
PASSENGER SEAT
LEVER UNDER THE HOOD
PARTS PART NAME LOCATION
TRAILER
CONNECTION
WIRE
ON THE TOOLBOX
BEHIND THE
DRIVER’S SEAT
TIRE INFLATION
HOSE
ON THE TOOLBOX
BEHIND THE
PASSENGER SEAT
TOW HOOK
ON THE TOOLBOX
BEHIND THE
PASSENGER SEAT
WARNINGLAMP IN GLOVE BOX
