MAINTENANCE AND SERVICE
5
- 201 -
NO VALUE SYSTEM
R01 24V 40A IGNITION/START - 1
R02 24V 40A IGNITION/START - 2
R03 12V 20A POWER OUTLETS (SEALED RELAY)
R04 24V 20A LIGHTING WORKING LAMP
R05 24V 40A IGNITION/ACCESSORY
R06 24V 20A SHADE MOTOR - UP
R07 24V 20A ENGINE OFF
R08 24V 20A HORN
R09 24V 20A UREA MODULE AND UREA HEATERS
R10 24V 40A A/C MOTOR
R11 24V 20A REVERSE LAMPS & REVERSE WARNING
R12 24V 20A
UREA QUALITY AND LEVEL SENSOR &
NOX SENSORS & TURBO & EXHAUST GAS
RECIRCULATION
R13 24V 20A TRAILER AXLE LIFTING
NO VALUE SYSTEM
R14 EMPTY
R15 24V 40A CAB LIFTING MOTOR
R16 24V 20A AIR HORN
R17 24V 20A BRAKE LAMPS
R18 EMPTY
R19 24V 20A PARKING LAMPS
R20 24V 40A WINDSHIELD HEATING - 1
R21 24V 20A TRIPLE DOME PARK LAMPS
R22 EMPTY
R23 24V 20A DOME BEACON
R24 24V 20A MIRROR HEATERS
R25 24V 40A WINDSHIELD HEATING - 2
R26 24V 20A DOOR LOCKING BUTTONS
R27 24V 20A SHADE MOTOR - DOWN
NO VALUE SYSTEM
F1 EMPTY
F2 150 A MEGA FUSE - ALTERNATOR
F3 175 A MEGA FUSE - GRILLED HEATER
F1 F2 F3
Fuse and Relay Table (On Engine)
Electrical Systems
