CONTROLS AND INDICATORS
3
FIGURE SYMBOL DESCRIPTON
1 EMPTY
2
SEMI-TRAILER BRAKE
3
INSPECTION OF FRONT SUSPENSION
LEVEL
3
INSPECTION OF SUSPENSION LEVEL
4
TIPPER LIFTING
5
AUXILIARY HEATER (DRY TYPE)
5
AUXILIARY HEATER (WET TYPE)
6 TRAILER AXLE LIFTING
7
EMERGENCY BRAKING SYSTEM
8
LANE DEPARTURE WARNING SYSTEM
9
MANOEUVRE MODE SELECTION
10
TRANSMISSION POWER MODE
SELECTION
FIGURE SYMBOL DESCRIPTON
10
TRANSMISSION POWER MODE
SELECTION
11
EBS CANCEL / EBS ACTIVE
12
DIFFERENTIAL LOCK
13
HILL LAUNCH ASSIST
14
AUTOMATIC HYBRID BRAKE
15
DIESEL PARTICULATE CLEANING ACTIVE
15
DIESEL PARTICULATE CLEANING
DEACTIVED
*16
CENTRAL LAMPS / READING LAMP
ON/OFF (LEFT) BUTTON
*16
ON /OFF (RIGHT) BUTTON OF THE
READING LAMP OF THE CENTER LAMPS
17
WARNING SWITCH HAZARD FLASHER
18
HANDBRAKE
19
ELECTRICAL CIRCUIT BREAKER
When the keys specifi ed with an asterisk (*) are pressed more than 1 or 2
seconds, it is possible to achieve an illumination starting at a low level and
increasing to higher levels.
Some features may not be available on your vehicle depending on the
vehicle version.
