Fourtec DaqPRO 5300 - External Connections

4 Chapter 1 DaqPRO
1.1.2. External Connections
Figure 1: DaqPRO external connections
1
st
in
p
ut
2. PC USB
connection
socket
3. Power input
(DC 9 – 12V)
1. Sensor
Inputs/Alarm
output
8
th
input/output
