Chapter 2 Working with DaqLab 69
2. Derivative
Click Derivative
on the main toolbar to construct a graph in which each point is the slope of the 3
consecutive points on the source graph.
3. Integral
Choose Integral from the Analysis menu to construct a graph in which each point is the integral of all
the preceding points on the source graph.
2.6.7. The Analysis Wizard
1. Using the Analysis Wizard
The Analysis Wizard will guide you through the various analysis functions available in the DaqLab
program. The analysis functions are grouped into three main categories: Curve fit (regression),
averaging, and mathematical and trigonometric functions.
To apply an analysis function to a data set:
a. Use the cursors to select the graph or data range to which you would like to apply
the analysis.
b. Click Analysis Wizard
on the main toolbar.
c. Click a Category tab:
Curve fit
Averaging
Functions
