30 Chapter 2 Working with DaqLab
2.3. Getting Started
2.3.1. Setting up a Recording Session
1. Prepare DaqPRO
a. Connect DaqPRO to the PC (refer to page 4)
b. Turn on DaqPRO
c. Plug in any external sensors
d. Open the DaqLab software
You can open DaqLab by double clicking its icon
on the desktop or from the start menu
2. Setup the DaqPRO
a. Click Setup Wizard
on the main toolbar
b. Follow the instructions in the Setup Wizard (refer to page 47)
3. Start Recording
a. Click Run
on the toolbar to start recording.
If the recording rate is 100 measurements per second or less, DaqLab automatically
opens a graph window displaying the data in real time, plotting it on the graph as it is
being recorded. If the recording rate is higher than 100/s, the data will be downloaded
and displayed automatically, once the data recording is finished.
b. You can stop recording anytime by clicking Stop
on the toolbar.
