Fourtec DaqPRO 5300 - Print; Print a Graph; Print a Table

Chapter 2 Working with DaqLab 35
2.3.9. Print
1. Print a Graph
a. Click Print
on the main toolbar.
b. Select the Graph 1 option (when in split graph mode you can choose between
Graph 1 and Graph 2).
c. Click Print to open the print dialog box.
d. Click OK.
DaqLab will print exactly what you see in the graph display.
2. Print a Table
a. Click Print
on the main toolbar.
b. Select the Table option.
If you want to print only a specific range, uncheck the Print all data check box and
type the desired row numbers into the To and From text boxes.
c. Click Print to open the print dialog box.
d. Click OK.
DaqLab will print exactly what you see in the table display as well as the DaqPRO
comment, serial number and the alarm level setup. Data that exceeds any of the
alarm levels will be highlighted by arrows.
