18 Chapter 1 DaqPRO
System
Information
Display system information:
1. Comment (use DaqLab to enter a comment)
2. Number of files stored in DaqPRO’s internal memory
3. Memory usage
4. Ambient temperature (the readings of the internal temperature sensor)
5. Current date and time
?
Help
On-line help and specifications
Configuration
Configure the DaqPRO:
Compensation method – Select between internal or external temperature
compensation for thermocouple measurements.
If you choose the external compensation you must connect an NTC 10k
temperature probe to input 1 and the thermocouple sensor to any other input,
and then setup the device accordingly.
Average – Select number of averaging points
Temperature units – Select between Fahrenheit and Celsius
Clear memory – Delete the stored data files
Contrast – Use the arrow buttons to tune the screen contrast
1.2.4. Graphic Display
DaqPRO will automatically use a graphic display in three cases:
• If the recording rate is every second or less and you selected Graphic Display in
the setup menu.
• Once logging has ended for a recording rate of over one per second.
