28 Chapter 2 Working with DaqLab
2.2. Overview
2.2.1. DaqLab On-screen Layout
DaqLab is a comprehensive program that provides you with everything you need in order to collect data
from the DaqPRO display the data in graphs, meters and tables and analyze it with sophisticated
analysis tools.
The program includes three windows: A graph window, table window, and a navigation window called the
Data Map. You can display all three windows simultaneously or in any combination.
The most commonly used tools and commands are displayed on two toolbars. Tools that relate to all
aspects of the program and tools that control the DaqPRO are located in the main (upper) toolbar. Tools
specific to the graphs are located on the graph (lower) toolbar.
2.2.2. Working with Projects
Every time you start a new recording, DaqLab automatically creates a new project file. All the information
you collect and process for a given session is stored in a single project file. Each of these files contain all
the data sets you collect with the DaqPRO, the analysis functions you’ve processed, specific graphs
you’ve created, and the DaqLab settings for the recording.
Note: All data sets in a single project must be with the same sampling rate.
