Chapter 2 Working with DaqLab 59
To change the password:
a. Click Logger on the menu toolbar, and then click Calibration > Calibrate
Sensors.
b. Click Change Password to open the Change Password dialog box.
c. Enter the current password in the Current Password text box.
d. Enter the new password in the New Password text box.
e. Enter the new password a second time in the Confirm New Password text box to
confirm your new password.
f. Click OK.
Note: The password must include at least 4 characters and is case sensitive.
6. Calibration Procedure
Two-point Calibration
Measure two reference values
a. Connect DaqPRO to the PC.
b. Click Logger on the menu bar, then click Calibration > Calibrate Sensors.
c. Enter the calibration password, and then click OK.
d. Choose a sensor from the Select sensor drop-down menu and click OK to open
the Sensor calibration dialog box:
