42 Chapter 2 Working with DaqLab
Map. If you want to save a graph that you created to your project, or to update a saved graph with
changes you made, use the Add to project tool:
Click Add to project
on the graph toolbar.
2.4.3. The Table Display
Click Table to display or to remove the table window.
The data in the table always matches the data that is currently displayed on the graph.
When you start a new recording, DaqLab displays the new data in the table as well as on the graph.
1. Formatting the Table
Changing column width
Drag the boundary on the right side of the column heading until the column is the desired width.
Changing row height
Drag the boundary below the row heading until the row is the desired height.
Formatting the fonts
a. Click Table on the menu bar, then click Properties.
b. Select the Font tab.
c. Format the font, as well as the font’s style and size.
d. Click OK.
Changing units and number format
a. Click Table on the menu bar, then click Properties.
b. Select the Units tab, and then select the plot you want to format from the Select
plot drop-down menu.
c. Choose the prefix option.
d. Select the desired number of decimal places.
