20 Chapter 1 DaqPRO
1.2.5. Load the Last Setup
When you turn DaqPRO on, once the self-testing has been completed, the following will be displayed:
_ _ _ INITIALIZATION _ _ _
DaqPRO ver 3.0h
Init. Display
Init. RAM
Loading SETUP…
The last setup is then automatically loaded.
1.2.6. Configuring your DaqPRO
Use the System Configuration menu to select the thermocouple temperature compensation method, to
select number of averaging points, to set temperature units, to clear the DaqPRO’s memory or to
change the screen contrast.
In the MAIN MENU screen, select the System Configuration icon
to display the configuration
screen:
_ _ _ CONFIGURATION _ _ _
→ Int Compensation
Average 4 samples
Temperature in ° C
Clear memory ( > )
Contrast ( < ) ( > )
Use the Forward
and Backward arrow buttons to select the mode and then press the
Press the Enter button
to move to the next item. You can press the Escape button to
leave the configuration menu at any time, saving the new changes you made. Press the Enter button in
the last item (Contrast) if you want to go back to the first item (Compensation).
The new configuration will be saved until the next time you change it.
