Chapter 1 DaqPRO 17
Display – Select the way DaqPRO will display the data (at a rate of up to 1
sample per second):
1. Numeric – Displays the sensor values and the sample number
2. Meter – Displays all active sensors in a bar meter display along with their
values (without decimals)
3. Table – Displays the last 6 values of all the active sensors in a table (without
decimals)
4. Graphic – Displays a graphic representation of the sampled sensors
At rates higher then 1/s the DaqPRO will display the data in a graph at the end
of the logging period.
Start – Press the Forward arrow to start recording
fn
Function
Display statistics of the current data
1. Minimum – The minimum graph value
2. Maximum – The maximum graph value
3. Average – The graph average
Use the Enter button to browse the different sensors
Open
Open a stored data in graphic display
Use the Forward and Backward Arrow buttons to browse the stored files,
press the Enter button to open a file
Notes
Display user information
Use the Arrow buttons to browse the notes.
You can use the DaqLab software to edit the notes or to write new notes.
