QUANTUM
™
HD COMPRESSOR CONTROL PANEL
MAINTENANCE
090.040-M (NOV 2016)
Page 111
PRESSURE TRANSDUCER CONVERSION DATA
(DATA INSTRUMENTS MODEL SA)
Sensor
Voltage
100 psi
Range - psig*
200 psi
Range - psig*
300 psi
Range - psig*
500 psi
Range - psig*
Low High Low High Low High Low High
1.0 29.92" 19.74" 29.92" 9.57" 29.92" 7.0 " 29.92" 4.1
1.1 29.92" 14.65" 29.92" 0.3 29.92" 4.1 29.92" 16.6
1.2 29.92" 9.57" 29.92" 5.3 22.3" 11.6 17.1" 29.1
1.3 24.83" 4.48" 19.74" 10.3 7.0 " 19.1 4.1 41.6
1.4 19.74" 0.3 9.57" 15.3 4.1 26.6 16.6 54.1
1.5 14.65" 2.8 0.3 20.3 11.6 34.1 29.1 66.6
1.6 9.57" 5.3 5.3 25.3 19.1 41.6 41.6 79.1
1.7 4.48" 7. 8 10.3 30.3 26.6 49.1 54.1 91.6
1.8 0.3 10.3 15.3 35.3 34.1 56.6 66.6 104.1
1.9 2.8 12.8 20.3 40.3 41.6 64.1 79.1 116.6
2.0 5.3 15.3 25.3 45.3 49.1 71.6 91.6 129.1
2.1 7.8 17.8 30.3 50.3 56.6 79.1 104.1 141.6
2.2 10.3 20.3 35.3 55.3 64.1 86.6 116.6 154.1
2.3 12.8 22.8 40.3 60.3 71.6 94.1 129.1 166.6
2.4 15.3 25.3 45.3 65.3 79.1 101.6 141.6 179.1
2.5 17.8 27.8 50.3 70.3 86.6 109.1 154.1 191.6
2.6 20.3 30.3 55.3 75.3 94.1 116.6 166.6 204.1
2.7 22.8 32.8 60.3 80.3 101.6 124.1 179.1 216.6
2.8 25.3 35.3 65.3 85.3 109.1 131.6 191.6 229.1
2.9 27.8 37.8 70.3 90.3 116.6 139.1 204.1 241.6
3.0 30.3 40.3 75.3 95.3 124.1 146.6 216.6 254.1
3.1 32.8 42.8 80.3 100.3 131.6 154.1 229.1 266.6
3.2 35.3 45.3 85.3 105.3 139.1 161.6 241.6 279.1
3.3 37.8 47.8 90.3 110.3 146.6 169.1 254.1 291.6
3.4 40.3 50.3 95.3 115.3 154.1 176.6 266.6 304.1
3.5 42.8 52.8 100.3 120.3 161.6 184.1 279.1 316.6
3.6 45.3 55.3 105.3 125.3 169.1 191.6 291.6 329.1
3.7 47.8 57.8 110.3 130.3 176.6 199.1 304.1 341.6
3.8 50.3 60.3 115.3 135.3 184.1 206.6 316.6 354.1
3.9 52.8 62.8 120.3 140.3 191.6 214.1 329.1 366.6
4.0 55.3 65.3 125.3 145.3 199.1 221.6 341.6 379.1
4.1 57.8 67.8 130.3 150.3 206.6 229.1 354.1 391.6
4.2 60.3 70.3 135.3 155.3 214.1 236.6 366.6 404.1
4.3 62.8 72.8 140.3 160.3 221.6 244.1 379.1 416.6
4.4 65.3 75.3 145.3 165.3 229.1 251.6 391.6 429.1
4.5 67.8 77.8 150.3 170.3 236.6 259.1 404.1 441.6
4.6 70.3 80.3 155.3 175.3 244.1 266.6 416.6 454.1
4.7 72.8 82.8 160.3 180.3 251.6 274.1 429.1 466.6
4.8 75.3 85.3 165.3 185.3 259.1 281.6 441.6 479.1
4.9 77.8 87.8 170.3 190.3 266.6 289.1 454.1 491.6
5.0 80.3 90.3 175.3 195.3 274.1 296.6 466.6 504.1
At zero psig 1.388 V 1.788 V 1.094 V 1.494 V 1.046 V 1.346 V 0.968 V 1.268 V
* Below 0 psig measured in inches of mercury.
090.040-TB0016.indd
Table 16. Pressure Transducer Conversation Data (Data Instruments Model SA)
SECTION 10
-
ADDITIONAL TABLES
TABLES
