QUANTUM
™
HD COMPRESSOR CONTROL PANEL
MAINTENANCE
090.040-M (NOV 2016)
Page 113
* Based upon system voltage
Frick
Number
SAP
Number
Description
Analog Boards
(1)
640C0062G01 1107799 Analog Board #1 (Replaces existing “614” analog board only - no hardware)
640C0062G02 1107800 Analog Board #2 (Replaces existing “614” analog board only - no hardware)
640C0062G11 1108061 Analog Board #1 Field Upgrade Kit (Requires HD software version 10.16 or later and 24 VDC)
640C0062G12 1108062 Analog Board #2 Field Upgrade Kit (Requires HD software version 10.16 or later and 24 VDC)
(1)
Note: If replacing an older style analog board, contact Frick Service for details.
Circuit Breakers
639A0206H10 484043 5 Amp circuit breaker
639A0206H10 484050 10 Amp circuit breaker
639A0206H12 484053 15 Amp circuit breaker
Connectors
649A1027G14 643440 2- Pole connector (P8 - Analog Board)
649A1027G11 485874 Connector kit for Input Ch. 1-16 (Analog Board)
649A1027G21 643460 Connector kit for Input Ch. 17-24, and Output Ch. 1-8 (Analog Board)
649A1027G31 643461 Connector for Power/Communications for Analog Board
Control Power
333Q0001418 467096 Filter, Line
333Q0001191 467024 Hour meter
639A0185H10 483963 2-Pos. Selector Switch (Control Power)
639A0185H30 483966 Latch, 3 Across (Attaches contact block to switch mechanism)
639A0185H31 483967 Normally Open Contact Block (for Control Power Switch)
639B0120H51 680313 Socket, Guarded, DPDT
639B0114H51 580348 Socket, Guarded, 3PDT
639B0114H98 580349 Spring Clip Hold Down
639B0120H01 680049 Relay, Control 24VDC, DPDT
639B0120H11 680311 Relay, Control 120VAC, DPDT
639B0120H21 680312 Relay, Control 240VAC, DPDT
639B0114H02 580342 Relay, Control 24VDC, 3PDT
639B0114H12 580345 Relay, Control 120VAC, 3PDT
639B0114H22 580347 Relay, Control 240VAC, 3PDT
639A0243H02 817257 Surge suppresser
Digital Boards
333Q0001172 467015 Output Module, 24 VDC
111Q0281061 455056 Output Module, 24-280 VAC
333Q0001171 467014 Input Module, 24 VDC
333Q0000116 466842 Input Module, 120 VAC
333Q0000789 466949 Input Module, 230 VAC
333Q0001326 467073 Fuse, 5 amp, 250 V
640C0024G01 484494 Digital Board #1 (Replaces existing board only - no hardware)
640C0024G02 484495 Digital Board #2 (Replaces existing board only - no hardware)
649D5948G01 826167 Digital Board #2 (Field Upgrade Kit- adds a second digital board)
Frick
Number
SAP
Number
Description
Display Accessories
639D0199H01 703164 15” Color Display (Indoor)
639D0199H11 845829 15” Color Display (Outdoor)
649D6101G01 1032704 Field Replacement Touchscreen glass w/overlay of Frick logo (Keypad has been eliminated)
Fans
649A0906G13 509129 Internal Circulation Fan, Field Install, 24 VDC
649A0906G11 485514 Internal Circulation Fan, Field Install, 115 VAC
649A0906G12 N/A Internal Circulation Fan, Field Install, 220 VAC
Flash Cards and Software
649A1104Gxx 831157
Quantum HD Program Flash Card (Version 10.xx, the “xx” indicates program revision)
649A1063G99 485995
Quantum HD Setpoint Saver (USB Drive)
Harnesses
639D0204H01 716617
DC power-l/O Comms harness
639D0203H01 716615
AC harness for digital board # 1
639D0203H02 716616
AC harness for digital board # 2
639B0118H01 670744
Display Harness
639B0126H01 884854
LED Inverter Harness
639D0191H03 696516
Harness Kit, Q5 to Interface Board Interconnect
Miscellaneous
333Q0001786 886046
Battery, 3V (located on Q5 board)
639C0143H01 670593 Q5 mounting plate (hardware not included)
Panel Heaters
640M0007G16 484626
200 W, 115 VAC
640M0007G18 484627
400 W, 115 VAC
640M0007G27 484632
200 W, 220 VAC
640M0007G21 484629
400 W, 220 VAC
Power Supply
639B0115H01 642307
DC power supply - 5 VDC
639B0115H02 642308
DC power supply - 12 VDC
639B0115H03 642309
DC power supply - 24 VDC
Q5 Boards
649C1158G01 1034948
Q5 (Advantech Q5) (Does not include interconnect harness kit)
639B0116H01 677556
Interface Board (Does not include interconnect harness kit)
090.040-TB0018.indd
Table 18. HD Compressor Control Replacements Parts List
SECTION 11
- REPLACEMENT PARTS LIST
CONTROL PANEL REPLACEMENT PARTS LIST
