STATUS - PANEL (IO COMMS)
STATUS - PANEL (COMMS 1-3)
DESCRIPTION: The Comms 1-3 screen is for informational
use, and provides the current status of each of the three us-
able serial communications ports. When a particular port is
in use, the status for that port will change from Off to Active
(to indicate it is functioning) or Failed (if the port is trying to
communicate, but has timed out).
Additionally on this screen is the current value of the Panel
ID number. The Panel ID is set by accessing the Menu >
Conguration > Communications > Serial tab.
DESCRIPTION: The I/O Comms screen is for informational
use, and provides the current software version of each of
the installed and recognized I/O control boards. Additionally,
the current communications status is shown for each board.
ACCESSING:
Panel Comms 1-3
090.040-PH0022.tif
ACCESSING:
Panel IO Comms
090.040-PH0023.tif
