Froling P4 Installation Manual

Technology
Components, Connections, and Dimensions
Page 14
M0930207 I
2
2.2 Dimensions
P4 Pellet
Dimensions
Description
Unit
8 / 15
20 / 25
32 / 38
48/60
80/100
L
Length, boiler
1)
inches
29⅛
29⅛
32¼
35½
39⅜
L1
Total length inc. induced draught
fan
37
37
40⅛
43¼
42⅛
B
Width, boiler
inches
23⅝
30⅜
33¾
40½
48⅝
B
*
Width, boiler, inc. support for
positioning unit
2)
27¾
34½
38
50¼
58¼
B1
Total width, inc. suction cyclone
46⅝
53⅜
56¾
70½
82
H
Height, boiler
3)
inches
50⅜
50⅜
56⅜
62⅜
67⅜
H1
Total height, inc. suction cyclone
65⅜
65⅜
74⅞
74⅞
74⅞
H2
Height, flue pipe connection
53⅛
53⅛
60¼
66⅜
70¼
H3
Height, outfeed connection
18⅛
18⅛
18⅛
20¼
20½
H4
Height, return connection
37
37½
42¾
48⅞
53½
H5
Height, drainage connection
18⅛
18⅛
18⅛
20¼
20½
H6
Height, ventilation connection
40½
40½
45½
51½
56¼
H8
Height, induced draught fan
connection
43
43
47⅞
54⅛
58⅞
H15
Height, suction system connection
58¼
58¼
67¾
67¾
67¾
Flue pipe diameter
inches
5
5
6
6
8
1) Corresponds to the minimum positioning length
2) Corresponds to the minimum positioning width after removing the stoker assembly, suction cyclone and positioning unit
3) Corresponds to the minimum positioning height after removing the stoker assembly, suction cyclone and positioning
unit

Froling P4 Specifications

General

Model	P4
Category	Boiler
Fuel Type	Wood Pellets
Automatic Ignition	Yes
Automatic Cleaning	Yes
Touchscreen Control	Yes
Remote Monitoring	Yes
Weight	Varies depending on model
Dimensions (H x W x D)	Varies depending on model
