Froling P4 - Variant 2 - Eco Pellet Box

Installation
Install delivery system
Page 36
M0930207 I
3
Variant 2 - Eco Pellet Box
 Place the wall installation module (F) by the hole
in the wall.
 Secure the insertion module to the wall using
four M8x50 frame screws and 10 mm Rawlplugs.
 Pack the space in the hole in the wall with a non-
flammable material.
 Place the wall cover plate (J) on the installation
module pipes.
 Secure the cover plate to the wall using four
M8x50 frame screws and 10 mm Rawlplugs.
 Fit 2 cover plates (H) to the installation module
using two star-shaped screws (I).
 Fit change unit (G) with 2 star-shaped screws.
 The position of the change unit is not
specified!
F
J
G
I
H
