Igniter
❒ Fit the clamp to the igniter tube using screws
Fix the cable with the cable ties supplied.
There must not be any loose cables in the area of the igniter.
Only connect the power supply after completing assembly.
Notice! The individual units should be checked by a qualified
technician and adjusted if necesary during initial start-up.
3.4 Assembling the pellet boiler
3.4.1 Before Installation
Checking the seal of the ash doors
❒ Open the door
❒ Insert a sheet of paper at the top between the door and boiler.
❒ Close the door.
❒ Try to pull the sheet of paper out.
If the paper cannot be removed:
The door seal is OK and the settings are correct.
If the paper can be removed:
The door is not sealed properly and must be adjusted!
❒ Check the seal again after positioning the doors.
❒ Repeat the procedure at the bottom of the ash door and on the side of the
door handle above and below the door handle as well as at the same
positions on the other ash door.
