3.2 Setting up the Boiler Room
3.2.1 Removeing the boiler from pallet
❒ Remove packing bands with suitable tools.
❒ Lift off the cardboard.
❒ Remove the transport covers (1) from the insulated door(s) and ash
container as well as the cleaning devices (2).
❒ Remove the protective casing.
On the front of the boiler:
❒ Remove securing devices used during transportation on the left and right
side of the base.
❒ Remove two screws each on the left and right of the ash collecting plate
and remove the collecting plate.
❒ Pull out the floor insulation behind.
At the back of the boiler:
❒ Remove securing devices used during transportation on the left and right
side of the base.
❒ Lift boiler off pallet.
