Froling P4 Installation Manual

Technology
Components, Connections, and Dimensions
Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestrasse 12, A-4710 Grieskirchen Page 21
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com M0930207
3
❒ Wind up the unplugged cables.
❒ Open the clamps and take off the cover.
3.3.3 Dismantling the stoker unit
❒ Remove the covering of the cable
duct.
At the pellet module:
❒ Unplug the components:
▪ "Min level S4"
▪ "Grate drive M6"
▪ "Burn back flap M7"
▪ "Stoker motor M1"
▪ "Ignition E1"
❒ Pull out the cables of the unplugged components.

Froling P4 Specifications

General

Model	P4
Category	Boiler
Fuel Type	Wood Pellets
Automatic Ignition	Yes
Automatic Cleaning	Yes
Touchscreen Control	Yes
Remote Monitoring	Yes
Weight	Varies depending on model
Dimensions (H x W x D)	Varies depending on model
