General information
Mains voltage
measurement
for single-phase
power sources
With single-phase machines, the mains voltage must be measured manually us-
ing a FLUKE measuring device.
1
Enter the measured mains voltage in the box
2
[ ] Enable In Use
3
Under external measuring equipment, enter the FLUKE measuring device
used
Correcting set
values and load
resistances
If the values specified by the calibration software are not achieved, the set value
or load resistance may need to be modified.
Examples:
AccuPocket 150 / 400 Tig
Current calibration (M1: Set value [A] = 60 A / RLoad [mOhm] = 240 mOhm)
TransTig 2200 Job
Current calibration (M5: RLoad [mOhm] = 96 mOhm)
VarioSynergic 3400
Read the measured value for the respective level in the calibration program and
enter it in the "set value" box.
41
EN
