Fronius Calibration system 2.0 User Manual

Calibrating welding systems with SpeedNet
(TPS /i, iWave 300i - 500i)
Overview -
SpeedNet
MIG/MAG welding systems with external wirefeeder
-
TPS 320i / 400i / 500i / 600i
-
TPS 400i LSC ADV
MIG/MAG welding systems with integrated wire drive
-
TPS 270i C
-
TPS 320i C
TIG welding systems
-
iWave 300i - 500 DC
-
iWave 300i - 500i AC/DC
The power sources listed above have a SpeedNet port and are calibrated using
the following calibration process.
Connecting the
power source
and calibration
system
1
Plug the mains cable into the calibration system
2
Plug the mains cable into the grid
3
Switch on the mains switch
NOTE!
If there is a power connector for the high current socket on the power source,
use the adapter for the high current sockets to bayonet (42,0001,4482).
4
Connect the (+) power cable to the calibration system and the power source
5
Connect the sense lead (red) to the calibration system
6
Connect the (-) power cable to the calibration system and the power source
7
Connect the sense lead (blue) to the calibration system
8
Switch on the power source
9
Connect the SpeedNet cable to the calibration system and to a free Speed-
Net connection socket on the welding system
Connecting the
welding wire cal-
ibration system
NOTE!
The power cables are not relevant for calibration of the welding wire!
Establish data communication between the following:
▶
power source and calibration system (LocalNet, SpeedNet, USB, etc.)
▶
power source and wirefeeder (LocalNet, SpeedNet, USB, etc.)
▶
welding wire calibration system and calibration system
1
Connect the connection cable to the welding wire calibration system
IMPORTANT! A maximum of 3 connection cables (max. 15 m) can be used to
connect the welding wire calibration system and the calibration system!
2
Connect the connection cable to the calibration system
53
EN
