Fronius Calibration system 2.0 User Manual

Calibrating welding systems with USB / SpeedNet
Overview - USB Software version 1.0.28 and higher:
TIG welding systems
-
iWave 230i DC
-
iWave 190i / 230i AC/DC
MIG/MAG welding systems with external wirefeeder
-
TPS 320i / 400i / 500i / 600i
-
TPS 400i LSC ADV
MIG/MAG welding systems with integrated wire drive
-
TPS 270i C
-
TPS 320i C
The TPS /i power sources can be calibrated via both the SpeedNet port and the
USB port.
The power sources listed above have a USB port and are calibrated using the fol-
lowing calibration process.
Connecting the
power source
and calibration
system
Also required:
-
2 USB Ethernet adapters (supplied with the calibration system)
-
1 Ethernet cable with RJ45 plug connectors
1
Plug the mains cable into the calibration system
2
Plug the mains cable into the grid
3
Switch on the mains switch
NOTE!
If there is a power connector for the high current socket on the power source,
use the adapter for the high current sockets to bayonet (42,0001,4482).
4
Connect the (+) power cable to the calibration system and the power source
5
Connect the sense lead (red) to the calibration system
6
Connect the (-) power cable to the calibration system and the power source
7
Connect the sense lead (blue) to the calibration system
8
Switch on the power source
9
Only when calibrating iWave 230i DC and iWave 190i / 230i AC/DC:
In the power source setup menu under Ignition and mode settings, set the
HF ignition parameter to "off".
10
Connect the USB Ethernet adapter to the calibration system
11
Connect the USB Ethernet adapter to the USB port of the welding system
12
Connect the USB Ethernet adapter using the Ethernet cable
