Fronius Calibration system 2.0 User Manual

Calibrating welding systems with LocalNet (TPS,
TSt, MW, TT)
Overview - Loc-
alNet
Welding systems with external wirefeeder
-
TS 4000 / 5000
-
TPS 3200 / 4000 / 5000
-
TIME 5000 Digital
-
CMT 4000 Advanced
-
TSt 3500/5000
-
TSt 3500 / 5000 Rob
-
TSt 3500 / 5000 Syn
-
TSt 4000 / 5000 Pulse
Welding systems with integrated wire drive
-
TPS 2700
-
TSt 2200c (cable harness 43,0004,4850 also required)
-
TSt 2500c / 2700c / 3000 c Pulse / 3500c
TIG welding systems
-
TT 800 / 2200 / 2500 / 3000 / 4000 / 5000
-
TT 800 / 2200 / 2500 / 3000 / 4000 / 5000 Job
-
TT 2200 / 2500 / 3000 / 4000 / 5000 Comfort
-
MW 1700 / 2200 / 2500 / 3000 / 4000 / 5000
-
MW 1700 / 2200 / 2500 / 3000 / 4000 / 5000 Job
-
MW 2200 / 2500 / 3000 / 4000 / 5000 Comfort
Manual metal arc welding systems
-
TP 4000 / 5000 CEL
The power sources listed above have a LocalNet port and are calibrated using the
following calibration process.
Connecting the
power source
and calibration
system
1
2
1
Plug in the mains cable
2
Switch on the mains switch
