CAUTION!
Risk of injury from emerging welding wire.
As soon as the calibration process resumes, the welding wirefeed starts and the
welding wire emerges.
▶
Keep the welding wire calibration system away from the head and body and
wear suitable protective goggles.
▶
Make sure that when the welding wire emerges, it does not touch any elec-
trically conducting, earthed or live parts.
▶
Make sure that there is sufficient space for the emerging welding wire (ap-
prox. 10 m).
▶
Make sure that no one is endangered by the emerging welding wire.
20
Click on [OK] to start calibration of the wirefeeder system
When the calibration process is complete, a corresponding notification is dis-
played and the [Print calibration report] button is available.
21
Click [Print calibration report]
Calibration system / create report is displayed.
22
Enter the details to create the calibration report:
Under Template, select the language for the calibration report from the list
Enter the output path
Enter or search for ( [Browse] ) the file name
If the Signotec signature pad is connected and has been detected by the cal-
ibration system, a notification to this effect is displayed under Signature pad.
If not, check the connection of the Signotec signature pad to the calibration
system and then click on [Reconnect].
23
Sign the Signotec signature pad with the corresponding digital pen
24
Press [OK] on the Signotec signature pad
The signature is sent to the calibration software.
x ... Cancel signature
Refresh ... new signature
A corresponding notification is displayed after the signature has been re-
ceived successfully.
25
Click [Create PDF]
IMPORTANT! Only after the confirmation "PDF created successfully!" is dis-
played, will the calibration report be saved.
58
