Control elements, connections and mechanical
components of the SplitBox
Safety
WARNING!
Danger from incorrect operation.
This can result in severe personal injury and damage to property.
► All the functions described may only be used by trained and qualified personnel.
► Fully read and understand this document.
► Fully read and understand all the Operating Instructions for the system components,
especially the safety rules.
Control elements,
connections and
mechanical com-
ponents
Front of SB 500i R (right variant) Rear of SB 500i R (right variant)
Front of SB 500i R (left variant) Rear of SB 500i R (left variant)
No. Function
(1) Blanking cover for option 3
(2) Blanking cover for option 4
(1)(3) (6)
(9) (4)
(7)(8) (5)
(2)(10)
