Fronius MIG/MAG - Fitting the Welding Torch to the WF Robacta Drive (Conventional)

96
Fitting the weld-
ing torch to the
WF Robacta Drive
(conventional)
CAUTION!
Danger of property damage due to dirty or wet coupling point.
► Whenever the welding torch is fitted or removed, ensure that the coupling point is clean
and dry.
► Remove any coolant that has escaped from the coupling point.
1 2
3
4
1
42,0411,1315
45,0200,1261
2
3
4
