Connecting the SplitBox to the system components
Safety
WARNING!
An electric shock can be fatal.
Before starting the work described below:
► Turn the power source mains switch to the "O" position
► Disconnect the power source from the mains
► Ensure that the power source remains disconnected from the mains until all work has
been completed
CAUTION!
Risk of injury and damage from loose connections.
► All cables, leads and hosepacks must be properly secured, undamaged, insulated and
adequately dimensioned.
General
NOTE!
Also follow the instructions and information in the documents 42,0410,1946 and
42,0410,2010 when connecting the wirefeeder to the system components.
Connecting the
SplitBox to the
system compo-
nents
IMPORTANT! Whenever the torch hosepack is fitted or removed, ensure that the coupling
point is clean and dry. Remove any coolant that has escaped from the coupling point.
1
SB 500i R (right variant)
1
SB 500i R (left variant)
1
1
2
6
4
5
3
1
