Using the Operator Panel Menus and Keypad 217
WPS Setup
NOTE:
• WPS Setup is available only when the printer is connected using the wireless network.
Purpose:
To configure the wireless network using Wi-Fi Protected Setup
â„¢
(WPS).
Values:
*
1
WPS-PBC stands for Wi-Fi Protected Setup-Push Button Configuration.
*
2
WPS-PIN stands for Wi-Fi Protected Setup-Personal Identification Number.
NOTE:
• WPS 2.0 compliant. WPS 2.0 works on access points with the following encryption types: Mixed Mode PSK, WPA-PSK-AES,
WPA2-PSK-AES, Open (No Security)
IP Mode
Purpose:
To configure the IP mode.
Values:
NOTE:
• To set an IP address for IPv6 in Dual Stack mode, use the CentreWare Internet Services. For more information, refer to the
online Help on the CentreWare Internet Services.
TCP/IP
Purpose:
To configure TCP/IP settings. The change becomes effective after the printer is turned off and then on.
Values:
Push Button
Configuration
Start
Configuration
Configures the wireless setting with WPS-PBC*
1
.
PIN Code Start
Configuration
Configures the wireless setting using WPS-PIN*
2
assigned automatically by
the printer.
Print PIN Code Prints the PIN code. Confirm it when you enter the PIN code to your computer.
Dual Stack* Uses both IPv4 and IPv6 to set the IP address.
IPv4 Mode Uses IPv4 to set the IP address.
Get IP Address DHCP /
AutoIP*
Sets the IP address automatically. A random value in the range of 169.254.1.0
to 169.254.254.255 that is not currently in use on the network is set as the IP
address. The subnet mask is set as 255.255.0.0.
BOOTP Sets the IP address using BOOTP.
RARP Sets the IP address using RARP.
DHCP Sets the IP address using DHCP.
Panel Use this option when you want to set the IP address manually on the operator
panel.
IP Address When an IP address is being set manually, the IP is allocated to the printer using
the format nnn.nnn.nnn.nnn. Each octet that makes up nnn.nnn.nnn.nnn is
a value in the range of 0 to 254. 127 and any value in the range of 224 to 254
cannot be specified for the first octet of a gateway address.
Subnet Mask When an IP address is being set manually, the subnet mask is specified using the
format nnn.nnn.nnn.nnn. Each octet that makes up nnn.nnn.nnn.nnn is a
value in the range of 0 to 255.255.255.255.255 cannot be specified as the
subnet mask.
Gateway
Address
When an IP address is being set manually, the gateway address is specified using
the format nnn.nnn.nnn.nnn. Each octet that makes up nnn.nnn.nnn.nnn is
a value in the range of 0 to 254. 127 and any value in the range of 224 to 254
cannot be specified for the first octet of a gateway address.
To Next Page
